Jupiter 2004/3/2
Jupiter Image Information
- Date: 2004.03.02 23:15 PST
- Above average seeing with high and low clouds
- Images taken from driveway
- Three Jupiter moons from left to right are Io, Callisto and Europa.
- Great Red Spot
- Apparent equatorial diameter: 44.5
- Apparent polar diameter: 41.6
- Apparent magnitude: -2.50
- Azm: 154° 36'01"
- Alt: +50° 45'21"
Photo Information
- CAMERA: Meade LPI camera
- EXPOSURE: 0.354 sec
- GAIN: 50
- OFFSET: 50
- TRACK: on
- COMBINE: on
- SAVE EVERY IMAGE: off
- DARK SUB: off
- MIN QUALITY: 50
- EVALUATION COUNT: 10
- MONO: off
- KERNEL FILTER: EdgeEnhancedHard, Apply after 10 images
- HISTOGRAM BLACK: 0
- HISTOGRAM WHITE: 255
- HISTOGRAM LOG: off
- ROI: off
- OBJECT: Jupiter
- IMAGES: 25 images stacked
- FILE TYPE: BMP
- TRACKING: on Io
Imaging Equipment
- Telescope: Orion Argonaut™ 150mm Maksutov-Cassegrain telescope,
f/12 focal ratio, 1800mm focal length
- Barlow: Tele Vue 2x Barlow
- Telescope Mount: Orion EQ-3 mount with EQ-3M dual-axis DC motor drive on
Celestron vibration suppression pads
Imaging Processing
- All image stacking was done automatically by Meade LPI software.
- Cor Berrevoets Registax Version 2.1.14.0 beta, wavlett processed.
- Adobe Potoshop Version CS, unsharp mask, levels, and crop.
The below image is the cropped output of the Meade LPI software before RegiStax and Photoshop processing.
